卧式注塑机系列 JHPA10

卧式注塑机系列 JHPA10

10.2寸TFT宽屏 800*480 LCD ,高亮度LED背光
ARM处理器400MHZ WINCE6.0操作系统
高分辨率电阻式触摸屏
USB方式资料上传和下载
128M FLASH Rj45以太网接口施行联网功能
多CPU控制下位机提高控制精度
光电隔离式40点输入、48点输出
8组12bit模拟量输出同时支持电压和电流方式
8组16bit模拟量输入精度范围为0.01
I/O板为JHP7I/O,也可配JHP7XI/O
10.2-inch widescreen TFT 800 * 480 LCD, high-brightness LED backlight;
ARM Processor 400MHZ WINCE6.0 operating system;
High-resolution resistive touch screen;
USB mode data upload and download;
128M FLASH Rj45 Ethernet networking purposes;
Multi-CPU machines under the control bit to improve control accuracy;
40 optical isolated inputs, 48 outputs;
8 group supports both 12bit analog output voltage and current mode;
Eight 16bit analog input accuracy range of 0.01;
I/O board for the JHP7I/O, can also be equipped with JHP7XI/O;
